400Wh/kg Series
SLD4-7S150Ah
Use this SLD4-7S150Ah record as a structured RFQ starting point. Confirm final voltage, discharge profile, weight, dimensions, cycle life, connectors, BMS scope, and certification claims from the matching datasheet before quotation.
Structured
Spec fields
Linked
Application fit
Controlled
Documents
Capacity | 150000mAh |
Nominal voltage | 24.5V |
Energy | 3675Wh |
Energy density | 400Wh/kg |
Series | 7S |
C-rate | 3C |
Max charge current | 150.0A (1C) |
Charge cut-off voltage | 30.1V |
Discharge cut-off voltage | 17.5V@T>=0C 15.4V@T < 0C |
Continuous discharge | 300A(2C) |
Max discharge current | 450A(3C)@10S (SOC > 50%) |
Cycle life | 500 cycle |
Operating temperature | -40~55C |
Storage temperature | -20~40C |
Storage humidity | <85%RH |
Dimensions | 120*125*410mm |
Weight | approx. 9.5kg |
Power plug | AS150 (Optional) |
Balance plug | XH-8P(B0~B7) (Optional) |
What to confirm before quotation
This detail page is structured for engineering review, controlled documentation, and RFQ handoff.
RFQ confirmation checklist
For SLD4-7S150Ah, share the drone platform, target endurance, payload, current profile, connector and charger requirements, quantity, destination market, and required documents. Soarlid can then confirm whether this product variant is the right fit and provide source-backed datasheet details.
- Specification fields on this page are imported from the manufacturer catalog listing.
- Electrical performance should be confirmed from the matching datasheet before quotation.
- Datasheet and certificate files remain sales-controlled unless a document is explicitly published.
Inquiry path
Request datasheet fields for SLD4-7S150Ah
Send your platform requirements and the sales team can reply with available datasheet, sample, documentation, and customization next steps by email.
Attach context such as airframe, target voltage, payload, current profile, connector, volume, certificate needs, and project timeline when available.
